Polaris RANGER 1000 2020 - Skid Plate Service

11
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
11.35
3. Install the four push rivets
w
.
4. Reinstall the upper fender.
SKID PLATE SERVICE
• Remove the thirteen fasteners and washers
q
securing the skid plate to the vehicle and remove the
skid plate.
TORQUE
Skid Plate Fasteners:
6 ft-lbs (8 Nm)
BODY / FRAME
