9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
11.31
EXTERIOR BODY SERVICE
FRONT BUMPER SERVICE
REMOVAL
1. Remove the two fasteners retaining the bottom of the
bumper to the frame.
2. Remove the two fasteners
w
retaining the top of the
bumper to the frame.
3. Carefully pull the bumper straight out to remove it
from the vehicle.
INSTALLATION
1. Align the bumper mount to frame mount.
2. Loosely install the two fasteners retaining the top of
the bumper to the frame.
3. Loosely install the two fasteners retaining the bottom
of the bumper to the frame.
BODY / FRAME
