3.84
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
4. Install the upper radiator hose.
5. Install the lower radiator hose
r
.
6. Fill and bleed the cooling system. Ensure no leaks
are present. Refer to Coolant Service page 3.80.
7. Install the radiator access flap up.
8. Install the radiator support brackets
e
and four
support fasteners
q
&
w
. Torque to specification.
TORQUE
Radiator Support Fasteners:
42 in-lbs (5 Nm)
9. Install the hood.
RADIATOR FAN REMOVAL
1. Remove Radiator, See Radiator Removal /
Installation page
2. Disconnect cooling fan electrical connector.
3. Tilt radiator fan toward the front of the vehicle, then lift
fan up and out.
ENGINE / COOLING / EXHAUST
