Polaris RANGER 1000 2020 - Fuel Vent Line Routing (Evap Models)

5
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
5.11
FUEL VENT LINE ROUTING (EVAP MODELS)
• The fuel tank is vented through an EVAP system.
• The vent line
r
is routed from the fuel tank and into a Evaporative Emissions Canister
q
. The Purge line runs from
the Evaporative Emissions Canister
q
and is secured in a horizontal section of the frame
u
. The purge line is also
supported by the air intake duct in two places. The line connects to a Purge Valve
t
with a quick connect fitting. The
purge jumper line
y
routes from the purge valve to the air intake manifold. This line assembly is secured to the
purge port on the manifold and to the purge valve using a quick connect fitting.
• The Fresh Air Lines
i
are secured into a vertical section of the frame with a Vent Line Termination Fitting
e
and
runs through the Canister Filter
w
and into the Evaporative Emissions Canister
q
.
NOTICE
Image orientation is from the front passenger-side of the vehicle
NUMBER
PART DESCRIPTION
q
Evaporative Emissions Canister
w
Canister Filter
e
Vent Line Termination Fitting
r
Purge Line
t
Purge Valve
y
Purge Jumper Line
u
Purge Line Routing Clip
i
Fresh Air Lines
FUEL SYSTEM
