9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
10.7
BRAKE LINE CLOCKING
MASTER CYLINDER
ITEM DESCRIPTION ANGLE
q
To Tee Block 30° +/- 2.5°
w
To Right Front Caliper
25° +/- 2.5°
e
To Left Front Caliper
15° +/- 2.5°
BRAKE SYSTEM
