9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
GENERAL INFORMATION - STEERING / SUSPENSION
SERVICE NOTES - STEERING /
SUSPENSION
WARNING
Serious injury may result if machine tips or falls. Be
sure machine is secure before beginning any procedure
that requires machine lifting. Always wear eye
protection.
DANGER
The locking agent on the existing a-arm bolts was
destroyed during removal. DO NOT reuse old
hardware. Serious injury or death could result if
fasteners come loose during operation.
IMPORTANT
New ball joint bolts have a pre-applied locking agent
which is destroyed upon removal. Always use new
brake caliper mounting bolts upon assembly.
STEERING & SUSPENSION
SPECIFICATIONS
ITEM
STANDARD SERVICE LIMIT
Steering Wheel
Free-Play
0.8-1.0 in (20-
25 mm)
-
Wheel Toe Out
0.0 in (0.0 mm)
+/- 0.25 in (6.35
mm)
Spring
Adjustment
Threaded
Spanner
Wrench
-
Front
Suspension
Travel
10.0 in (25.4
cm)
-
Rear
Suspension
Travel
10.0 in (25.4
cm)
-
STEERING / SUSPENSION
