INSTALLATION
1. Install the front headliner and tuck behind the ROPS
on both sides.
2. Install the two T30 fasteners from the front headliner.
Torque to specification.
TORQUE
24 in-lbs (3 N·m)
3. Install the rear headliner and tuck behind the ROPS
on both sides.
4. Install the five push rivets to secure both headliners to
the windshield plate.
5. Install the two rear push rivets.
