3.13
3. Carefully push the grommets through the side bezel.
4. Carefully remove the duct from the lower closeoff
panel.
CAUTION
Use care not to tear the intake duct when removing
from the panel.
AIRBOX TO SIDE BEZEL INSTALLATION
1. Install the duct in the closeoff panel.
IMPORTANT
Ensure the duct is fully seated.
2. Carefully push the grommets through the side bezel.
ENGINE / COOLING / EXHAUST
