9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
1.13
ENGINE ELECTRICAL
PART DESCRIPTION TORQUE SPECIFICATION
CPS Retaining Fastener 9 ft-lbs (12 Nm)
ECT Sensor 16 ft-lbs (22 Nm)
ECU Retaining Fastener 22 in-lbs (2.5 Nm)
ETC Housing Retaining
Fastener
5 ft-lbs (7 Nm)
Ignition Coil Bracket
Fastener
7 ft-lbs (9 Nm)
Ignition Coil Retaining
Fastener
6 ft-lbs (8 Nm)
Oxygen Sensor 35 ft-lbs (47 N·m)
Spark Plug 15 ft-lbs (20 Nm)
T-MAP Retaining Fastener 3 ft-lbs (4.5 Nm)
Starter Cable Wiring Nuts 48 in-lbs (5 Nm)
Starter Motor Fasteners
7 lb-ft (10 Nm)
FUEL SYSTEM
PART DESCRIPTION
TORQUE SPECIFICATION
Carbon Canister Bracket
6 ft-lbs (8 Nm)
Fuel Pump Nut 70 ft-lbs (95 Nm)
Fuel Rail Mounting Fastener 5 ft-lbs (7 Nm)
Fuel Tank Bracket Fastener
10 ft-lbs (14 Nm)
PVT SYSTEM
PART DESCRIPTION
TORQUE SPECIFICATION
Drive Clutch Cover Fastener
44 in-lbs (5 Nm)
Drive Clutch Retaining
Fastener (Moveable sheave
removed only)
96 ft-lbs (130 Nm)
Drive Clutch Retaining
Fastener (If stationary
sheave was removed)
Step 1: 110 ft-lbs (149
Nm)
Step 2: Loosen
Fastener
Step 3: 96 ft-lbs (130
Nm)
Driven Clutch Helix Fastener
32 ft-lbs (44 Nm)
Driven Clutch Retaining
Fastener
20 ft-lbs (27 Nm)
PVT Cover to Engine
Fastener
37 ft-lbs (50 Nm)
PVT Cover to Transmission
Fastener
50 ft-lbs (68 Nm)
PVT Hose Adapter Clamps 35 in-lbs (4 Nm)
PVT Hose Ducting Fastener:
14 x 3/4
18 in-lbs (2 Nm)
PVT Inlet Hose Clamp 35 in-lbs (4 Nm)
PVT Inner Cover Fastener 5 ft-lbs (7 Nm)
PVT Intake Duct Hose
Fastening Nut: M6 x 1.0
72-78 in-lbs (8-9 Nm)
PVT Outlet Duct Fastener
7 in-lbs (1 Nm)
Shift Weight Fastener 20 in-lb (2 Nm)
GENERAL INFORMATION
1
