4. Remove the one-way clutch and inspect both sides of
drive rollers
r
. Inspect the roller contact surface
t
inside the hub for wear, damage or uneven surface.
5. Remove the starter gear from the engine and inspect
the drive surface of the starter gear
y
and the
bushing
u
for wear, damage or uneven surfaces.
NOTICE
If any starter one-way clutch component is worn or
damaged, replace the clutch and starter gear as an
assembly.
INSTALLATION
1. Install the one-way clutch
r
inside the hub
t
.
2. Clean screw threads in flywheel to remove all oil or
grease.
3. Install the one-way clutch
w
on the flywheel
e
and
secure with the three clutch fasteners
q
. Torque to
specification.
TORQUE
One-Way Clutch Retaining Screws:
9 ft-lbs (12 Nm)
