9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
1.17
CHASSIS / BODY ELECTRICAL
PART DESCRIPTION
TORQUE SPECIFICATION
Battery Box Fastener 42 in-lbs (5 Nm)
Battery Bracket Fastener 42 in-lbs (5 Nm)
Battery Terminal Fastener 40 in-lbs (5 Nm)
Chassis Ground
8 ft-lbs (11 Nm)
ECU Retaining Fastener
24 in-lbs (2.7 Nm)
Headlight Fastener 5 ft-lbs (7 Nm)
Ride Command Monitor
Mounting Bracket Fasteners
12 in-lbs (1.3 Nm)
Stator Fasteners
9 ft-lbs (12 Nm)
Tail Light Fasteners
4 lb-ft (5 Nm)
Terminal Block Fasteners
24 in-lbs (3 Nm)
Terminal Block Cables
30 in-lbs (3.5 Nm)
Throttle Pedal Mounting
Fasteners
8 ft-lbs (11 Nm)
GENERAL INFORMATION
1
