4.4
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
INJECTOR HARNESS
REF DESCRIPTION
q
PTO Fuel Injector Connector
w
MAG Fuel Injector Connector
e
Tree Clip (Into Intake Manifold)
r
Coolant Temperature Sensor Connector
t
Tree Clip (Into PVT Duct)
ENGINE ELECTRICAL
