6
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
6.13
5. Install the air duct and air duct clamp
w
. Torque to
specification.
TORQUE
PVT Air Duct Clamp:
35 in-lbs (4 Nm)
6. Install the drive clutch. Refer to Drive Clutch Removal
/ Installation page 6.9.
7. Install the driven clutch. Refer to Driven Clutch
Removal / Installation page 6.10.
8. Install the outer clutch cover. Refer to PVT Clutch
Cover Service page 6.7.
PVT SYSTEM
