REASSEMBLY
1. Install the clutch spider assembly.
2. Install the washer
y
, belleville washer
t
and clutch
spring
r
.
IMPORTANT
Belleville washer must be installed with dome facing the
outer post.
3. Using a clutch spring compressor, install clutch cover
q
and clutch cover bolts
w
. Torque the bolts in a
cross pattern to specification.
