Polaris RANGER 1000 2020 Service Manual

6.28
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
Perform clutch
alignment. Refer
to Driven Clutch
Alignment. Does
the vehicle
creep?
Warm clutches
up by driving at
moderate speeds
in high gear for 2
miles; Does
Vehicle come to a
stop?
→
No
Probable
interference
between
movable
sheave towers
and spider
buttons.
Remove belt
and drive
spring.
Reinstall
cover and
operate clutch
by hand. Is
there
resistance to
motion?
Inspect spider
rollers -
Remove the
drive clutch
cover by
referring to
Belt Removal.
Apply load on
each roller
firmly with
your finger
while rotating.
Do all three
rotate freely?
→
No
Service
Spider
Rollers.
Refer to
PVT Inner
Cover
Disassem-
bly.
Yes
↓ Yes ↓ Yes ↓ Yes ↓
Replace idle
bearing/slide
sleeve assembly
and helix. Refer
to Clutch
Inspection and
Bushing Service.
PVT System
operating
properly at this
time. No further
action is
necessary.
Remove
spider and
lightly sand
with a high grit
sandpaper
(220 or
higher).
Remove
material so
button rides
smoothly in
tower.
OR
Replace drive
clutch.
Inspect the
idle bearing
for free
rotation. Does
it rotate
freely?
→
No
Replace
the idle
bearing/
slide
sleeve
assembly
and helix
Yes
↓
If problem
persists,
replace the
drive clutch.
PVT SYSTEM
