When “Differential-Lock” is selected in either 2WD or
4WD, power is removed from the electrical solenoid
allowing the solenoid plunger to retract. Spring tension
moves the shift fork back into place and mates the
engagement dog to the side gear that is part of the
planetary differential assembly. This locks the rear
differential as a solid rear axle, increasing traction.
TRANSMISSION
