5. Install the propshaft on the front gearcase and drive a
new prop shaft pin into the propshaft.
6. Connect the AWD harness and tie the harness to the
brake lines with a plastic tie strap.
7. Add the proper lubricant to the front gearcase. Check
drain plug for proper torque. Refer to Maintenance
Chapter for fluid fill and change information.
