9. Remove the prop shaft pinch bolts.
10.Detach the front gearcase vent hose.
11. Disconnect the AWD wire harness.
12.Remove the upper front gearcase nut and bolt.
13.Remove the lower front gearcase nut and bolt.
14.Slide the propshaft off the splines of the front
gearcase.
15.Remove the front gearcase through the opening in
the front of the chassis.
FINAL DRIVE
