3. Inspect the inner ring gear / roller cage housing for a
consistent wear pattern. Inspect the ring gear for
chipped, broken, or missing teeth.
4. Inspect the roll cage assembly
t
sliding surfaces and
H-springs
y
. The sliding surfaces must be clean and
free of nicks, burrs or scratches. If damaged, replace
the roll cage assembly.
OUTPUT HUB / BEARING INSPECTION
1. Inspect both output hub assemblies. Inspect the
bearings and replace if needed.
q
Bearing
e
Inner Bushing / Spacer
w
Hub Assembly
e
Outer Bushing / Spacer
