8.49
7. Install the castle nut.
TORQUE
Rear Wheel Hub Castle Nut :
180 ft-lbs (245 N·m)
8. Install the cotter pin.
9. Install the rear brake caliper and torque the mounting
bolts to specification.
TORQUE
Rear Caliper Mounting Bolts:
46 lb-ft (62 Nm)
10.Install the wheel, washers and wheel nuts. Torque
wheel nuts to specification.
TORQUE
Wheel Nuts (Steel): 60 lb-ft (81 Nm)
Wheel Nuts (Alum): 120 lb-ft (163 Nm)
FINAL DRIVE
