10.30
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
5. Reinstall the applicable wheel hub assembly. Refer to
applicable installation procedure.
NOTICE
Each hub can require different numbers of washers and
torque values. This is based on the location on the
vehicle, and material of the hub. Make sure to use the
correct installation procedure for the hub being
serviced.
NOTICE
If replacing a rear brake disc, refer to Rear Hub
Identification page 8.4 to make sure that the correct
washer and washer quantity is used.
6. Reinstall the applicable brake caliper. Refer to
applicable caliper installation procedure.
7. Bleed brakes if needed. Follow the bleeding
procedure outlined earlier in this chapter.
8. Field test unit for proper braking action before putting
into service. Inspect for fluid leaks and firm brakes.
Make sure the brake is not dragging when pedal is
released. If the brake drags, re-check assembly and
installation.
BRAKE SYSTEM
