Polaris RANGER 1000 2020 - Page 543

11
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
11.55
4. Install the lower regulator fastener
r
.
TORQUE
Window Regulator Fastener:
8 ft-lbs (11 Nm)
5. Install the upper regulator support bracket and five
fasteners
e
to secure the bracket. Torque the
fasteners to specification.
TORQUE
Window Regulator Support Fastener:
6 ft-lbs (8 Nm)
6. Reconnect the speaker and window harness from the
regulator support.
7. Install the three window motor fasteners
q
and
window regulator fastener
w
. Torque to specification.
TORQUE
Window Regulator Fastener:
8 ft-lbs (11 Nm)
TORQUE
Window Motor Fastener:
Torque until fully seated
8. Install the door panels.
BODY / FRAME
