12
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
12.13
FLOOR TUNNEL ROUTING
REF DESCRIPTION
q
Seat Belt Switch Connector
w
Tree Clip (Into Trim Panel)
e
Harness Guide Tunnel
r
Harness Retention Covers
CHASSIS / BODY ELECTRICAL
