Polaris RANGER XP 1000 2018 - Intake System Assembly View

3
9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
3.13
INTAKE / EXHAUST SERVICE
INTAKE SYSTEM ASSEMBLY VIEW
ITEM DESCRIPTION
TORQUE
q
Fresh Air Intake Line NA
w
Engine Intake Elbow
NA
e
Clutch Intake Elbow NA
r
Intake Duct Clamps 35 in-lbs (4 Nm)
t
Intake Hard Line NA
ENGINE / COOLING / EXHAUST
