9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
ROCKER PANEL REMOVAL
1. Remove the push rivet
q
on the inside of the rear
upper fender and the two T-40 fasteners
w
retaining
the lower fender cover.
TORQUE
Lower fender fasteners:
42 in-lbs (5 Nm)
2. Remove the two push rivets
e
on the back side of
the rear upper fender. Lift up and remove the upper
fender.
3. Remove the remaining eight T-40 fasteners
r
and
push rivet
t
retaining the lower fender. Remove the
lower fender.
TORQUE
Lower fender fasteners:
42 in-lbs (5 Nm)
BODY / FRAME
