9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
3.109
A/C CONDENSER CLEANING
1. Position the vehicle on a level surface, place the
transmission in PARK and stop the engine.
2. Remove the front hood panel by turn the 1/4 turn
fasteners.
3. Remove the two fasteners
q
and two fasteners
w
.
Remove the supporting brackets.
4. Remove the two push rivets
e
retaining the
condenser cover.
5. Tilt the condenser cover upwards on the folding
crease
r
to gain access to the condenser.
6. Clean condenser as needed.
CAUTION
Do not use high pressure washers to clean the
condenser or damage to cooling fins may result.
NOTE
Front fascia removed or clarity.
7. Reassemble vehicle.
ENGINE / COOLING / EXHAUST
