9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
3.95
11. Install the four coolant hoses
u
–
a
that attach to the
water pump. Be sure orientation and routing are
correct.
12.Install the right rear lower shock bolt and new nut.
Torque mounting bolt to specification.
TORQUE
Rear Shock Mounting Bolt:
40 ft-lbs (54 Nm)
13.Install the right rear wheel. Torque wheel nuts to
specification.
TORQUE
Wheel Lug Nuts:
120 ft-lbs (163 Nm)
14.Connect the (-) negative battery cable.
15.Fill and bleed cooling system as outlined in this
chapter.
16.Install the hood and seats.
WATER PUMP SERVICE
NOTE
The water pump cover gasket can be replaced while
the water pump housing is still installed in the engine.
1. Remove water pump assembly as outlined in this
chapter (Engine Disassembly/Inspection - Bottom
End — Water Pump Housing Removal).
2. Remove the three bolts retaining water pump cover
q
to water pump housing
w
. Discard cover gasket
e
.
3. Place the water pump drive tab
r
vertically into a soft
jaw vice.
4. Remove the bolt and washer retaining the water
pump impeller to the shaft. Inspect the impeller veins
and water pump housing for damage. Replace if
needed.
NOTE
The water pump impeller bolt
t
is left hand thread
(reverse thread).
5. Remove impeller from water pump shaft.
ENGINE / COOLING / EXHAUST
