9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
RADIATOR REMOVAL / INSTALLATION
1. Remove the hood.
2. Remove four upper radiator support fasteners
q
&
w
. Remove the two radiator support brackets
e
.
3. Lift the radiator access flap up.
4. Drain radiator by removing lower radiator hose
r
. Be
sure to catch and dispose of coolant properly.
WARNING
The cooling system is under pressure and serious
burns may result.
Allow the engine to cool before servicing.
5. Remove the upper radiator hose from the radiator.
6. Disconnect the small radiator bypass hose
t
.
7. Remove four fasteners
y
securing the radiator fan to
the radiator. Separate the fan motor assembly from
the radiator.
ENGINE / COOLING / EXHAUST
