3.16
9928487 R01 - 2018 RANGER XP 1000 Service Manual
© Copyright Polaris Industries Inc.
9. Loosen intake boot Hose Clamps
o
at cylinder head.
IMPORTANT
Make note of Hose Clamps orientation for installation.
10.Loosen Intake Manifold Mounting Bolt
a
located at
the transmission bracket.
11. Remove Intake Manifold from engine.
ENGINE / COOLING / EXHAUST
