RealPresence Collaboration Server (RMX) 1500/1800/2000/4000 Getting Started Guide
Polycom®, Inc. 34
Telescopic Rail Runner Assembly
1 Determine the location of the Collaboration Server on the rack:
Allow for a 1U gap above and below the system for ventilation.
Use the Rack Spacer (item no. 3) to predetermine its position on the rack post, making sure that
square studs of the spacer fit into the rack post’s square/rounded mounting holes. Mark the
spacer’s location on the rack post. Repeat this process for the 3 remaining vertical posts ensuring
that the system can be horizontally seated.
Rail runner assembly kit Flat head screw - M3*8mm 5 4
Flat washer M3 6 4
Nut spring M3 7 4
Collaboration Server
chassis assembly kit
Pan head screw - M5*12mm 8 2
Flat washer M5 9 2
Rack Rail Runners require a minimum of 48cm and a maximum of 80cm within the rack for
installation
Rail Runners Kit Contents
Part/Kit no. Item Item
no.
Item Sample Item
Quantity
