Qirod QD100 Series User Manual

106
e-23
Braking
resistance
overload

Improper
selection of
braking
resistance

Choose more
suitable braking
resistor for working
condition

Disable braking
resistor load protection
F527=2
e-24
Inverter
overheat
fault

Inverter’s
cooling fan does
not work.

Environment
temperature is
too high.

Certain
ventilation
opening is
blocked.

There is heat
source near the
inverter.

Reset the inverter’s
fault after cooling and
restart the inverter.

Expand the free
space around the
inverter; Remove all
heat sources near the
inverter to lower the
environment
temperature.
e-25
Motor PTC
overheatin
g fault

External PTC
embedded in the
motor winding
indicates
existence of
motor
overheating.

Correct motor
overheating.

Check whether PTC
is working properly.

Check logic input
functions 27 and 28.
Code of
fault
Type of fault
Possible cause
Measures
(troubleshooting)
