Raider 50 - Page 153

Lower Unit
RO
q
9
0
7
GEAR
GEAR
GEAR
GEAR
9
0
4. Attach shim 0 used on the reverse (C) gear 9 to the
gear.
Use a suitable press to install reverse (C) gear 9.
Clean reverse (C) gear bearing installation face
and apply gear oil before installation.
Bevel Gear Bearing Install Tool q :
P/N. 3C8-72719-0
GEAR
GEAR
7 Bearing
2
1
Do not reuse.
16) Disassembly of Propeller Shaft
Ass’y
1. Remove push rod 1 and steel ball 2.
3
7
6
5
4
3 Clutch Pin Snap Do not reuse.
2. Put a bladed screw driver into one of clutch pin snap 3
3
end, and take the snap out from the clutch groove while
winding it.
3 Clutch Pin Snap Do not reuse.
6-46
2st 50D2 2011
