Power Unit
5. Disconnect cooling water hose 6 (exhaust cover - water
check port)
6
6. Disconnect fuel hose 7 from fuel filter (fuel connector -
fuel filter)
7
7. Remove choke rod 8.
8
9
0
5-28
8.
Remove apron 9 and loosen engine mount bolts, then
remove them.
9. Carefully pry power unit by using steel pipe 0 to remove
power unit.
Easy to remove, when the part where the fulcrum
and action point are close is raised.
2st X50D2 2011
