Install birdscreen mounts into inlet hood opening.
Mount birdscreen into brackets and secure with self
tapping screws and washers.
*For Model 2030 only.
Description Part Number
Birdscreen 90740052 / 90740053
Birdscreen Mount 13205091 / 13305087*
Fender Washer 95211550
TEK Screw 13404
Attach the double-sided filter rails horizontally to the
face of the inlet hood using two #10-24 x ½" bolts
and #10-24 nuts on each side. When attaching the
filter rails, insert the bolt from the inside of the filter
rail to allow for maximum clearance for the filters.
Attach the filter clips with TEK self-tapping screws.
(First remove the washer as the washer will restrict
the filter clip, making it difficult to open.)
NOTE: Inlet hoods with birdscreen does not require
filters or snap fasteners.
Description Part Number
Double-Sided Filter Rails 13205066 / 13305066
#10-24 x ½" Bolt 27000
#10-24 Nut 20698
TEK Screw 13404
A1 Snap Fastener 20900
