Raritan PM Series User Manual

Chapter 3: Using the Web Interface
187
Protocols
NN
HTTP 01
SSH 02
TELNET 03
SNMP 05
MODBUS 06
• XX is a two-digit number representing the device position as shown
below.
Position
XX
Position
XX
Master device
00
Slave 8
08
Slave 1
01
Slave 9
09
Slave 2
02
Slave 10
10
Slave 3
03
Slave 11
11
Slave 4
04
Slave 12
12
Slave 5
05
Slave 13
13
Slave 6
06
Slave 14
14
Slave 7
07
Slave 15
15
For example, to access the Slave 4 device via Modbus/TCP, the port
number is 50604. See
Port Forwarding Examples (on page 188) for
further illustrations.
Tip: The full list of each cascaded device's port numbers can be retrieved
from the web interface. Choose Maintenance > Device Information > Port
Forwarding.
Standard TCP/UDP ports:
The master device can be also accessed through standard TCP/UDP
ports as listed in the following table.
Protocols
Port Numbers
HTTPS 443
