Chapter 3: Using the Web Interface
HTTP 80
SSH 22
TELNET 23
SNMP 161
MODBUS 502
In the Port Forwarding mode, the BCM2 does NOT allow you to modify
the standard TCP/UDP port configuration, including HTTP, HTTPS, SSH,
Telnet and Modbus/TCP.
Port Forwarding Examples
To access a cascaded device in the Port Forwarding mode, assign a port
number to the IP address.
• Master device: Assign proper 5NNXX port numbers or standard
TCP/UDP ports. See
Port Number Syntax
(on page 186) for details.
• Slave device: Assign proper 5NNXX port numbers.
Assumption:
The Port Forwarding mode is applied to a cascading chain
comprising three Raritan devices. The IP address is 192.168.84.77.
Master device:
Position code for the master device is '00' so each port number is 5NN00
as listed below.
HTTPS 50000
HTTP 50100
SSH 50200
TELNET 50300
SNMP 50500
MODBUS 50600
Examples using "5NN00" ports:
• To access the master device via HTTPS, the IP address is:
https://192.168.84.77:50000/
• To access the master device via HTTP, the IP address is:
http://192.168.84.77:50100/
