5.11 DIAGNOSTIC DATA (DIAG Group)
The DIAG (diagnostic) group displays some basic E1 Common Module information, and enables a
reset to factory default settings. (See Table 5-8).
Table 5-8. DIAG group
Function Description
T1/E1 Indicates the module's operating mode. On a CM4 module, this is always "E1".
#.## Indicates the module's firmware revision.
Fcty Return to factory default configuration: (See note below)
Framing ESF
Line Code B8ZS
Timing Internal (terminal multiplexers) or Through (D/I multiplexers)
Line Loopback OFF
Payload Loopback OFF
Equipment Loopback OFF
Fast Reframe OFF
TYPE T1
HEAD 75
LBO (Line Build Out) 0x00
CRC4 On
CSU RFL
POSQ Disabled
PRSQ Disabled
UNIV On
SWAP 0.6s
SWITCH Auto
MAIN On
FTIM (Fallback Timing) Int
JBUF (Jitter Buffer Depth) 32 bits
To set this function, push up twice on the SET/NEXT switch
NOTE
Returning to the factory default configuration in an E1 system
will cause the system to return to T1 defaults.
