7.8 OPTICAL INTERFACE ADAPTER REMOTE ACCESS
AND STATUS REPORTING
In IMUX 2000 multiplexers equipped with fiber optic interfaces, the Optical Interface Adapter (OIA)
plugs in as a Module Adapter behind the CM4 Common Module. Though it serves the function of a
Module Adapter, it acts as a channel module to the SCB (Serial Control Bus).
The OIA will always have a fixed channel address. When DIP switches SW1-1 and SW1-2 on the OIA
are set to the TERM or DI-A mode, the address is "C1." When SW1-1 and SW1-2 are set to the DI-B
mode, the address is "C3." The OIA reports itself as a "Type 11" module.
SRVC service is always on in the local mode, and may be turned off in the remote mode. However,
this has no effect on the module.
CHANNEL CARD 1 (or 3) TYPE 11
There is only one remote configuration setting ("P" code) for the OIA, as listed in Table 7-5. The
remote status messages ("S" codes) for the OIA are listed in Table 7-6.
Table 7-5. Remote configuration settings ("P" codes), Optical Interface Adapter
Parameter Possible Settings Description
SRVC ON Turn service on (enable module).
OFF Turn service off (disable module).
P01 0 Select B8ZS line coding.
1 Select AMI line coding.
Table 7-6. Remote status messages ("S"
codes), Optical Interface Adapter
Position Value Description
TX ALM (Transmit Alarm) is in its alarm state. B 0 1 1 1 1 1 1 1 0
IMUX 2000E1 RFL Electronics Inc.
1 TX ALM (Transmit Alarm) is in its normal state.
B 0 1 1 1 1 1 1 1 0 TX ACT (Transmit Activity) is in its alarm state.
1 TX ACT (Transmit Activity) is in its normal state.
B 0 1 1 1 1 1 1 1 0 LOCK is in its alarm state.
1 LOCK is in its normal state.
B 0 1 1 1 1 1 1 1 0 RX ALM (Receive Alarm) is in its alarm state.
1 RX ALM (Receive Alarm) is in its normal state.
↑
February 28, 2006 7-29 (973) 334-3100
