I N S T R U C T I O N D A T A
RFL DS-64NC Wideband Synchronous Data Module
DESCRIPTION
The RFL DS-64NC is a synchronous data channel module that can operate at a selectable data rate.
The rate can be any multiple of 8 Kbps, with a maximum limit that depends on the multiplexer type.
Ranges are as follows:
T1 Multiplexers and T1-Based Variable-Rate Multiplexers . 8 Kbps to 1.536 Mbps
2MB Multiplexers . . . . . . 8 Kbps to 1.984 Mbps
2MB-Based Variable-Rate Multiplexers . . . 8 Kbps to 1.984 Mbps
Features include the following:
o User-selectable data rate.
o Full independent send and receive timing (at the same nominal rate in both directions).
o One-way or full duplex operation.
o Choice of RS-449 or CCITT V.35 interface.
o Local and far-end loopbacks.
o Clear-channel operation for AMI networks.
o Test pattern generator and error detector for one-way or loopback testing.
o Contiguous or alternating time slot assignment.
o Time Slot 16 can be skipped for CAS multiframe applications (2MB multiplexers only).
o Remote control configuration and status reporting.
o Selectable transmit/receive direction.
o Optional deep buffers for plesiochronous operation.
Note: Please see Application Note on page 51 of this Instruction Data sheet.
