7.5.8 CHANGING COMMON MODULE SETUP PARAMETERS
The setup of a CM4 Common Module can be changed by issuing SET commands with the appropriate
parameter names and values. For example, to set line code to AMI in a terminal multiplexer with an
address of 11, issue the following command:
11:TERM:SET:FAST=ON;
Table 7-4 lists the CM4 setup parameters that can be changed remotely.
Table 7-4. Valid parameter names and values for SET commands issued to CM4 modules
Name Description Legal Value Sets Parameter To: Default
PASSWORD Shelf Security 16-character string Password none
(N/A for DI-B)
FRAMING* Frame Type CAS Channel Associated Signaling CAS
CCS Common Channel Signaling
CODE* E1 Line Code HDB3 High Density Bipolar of order 3. HDB3
AMI Alternate Mark Inversion
Primary timing mode INT Internal (terminal multiplexers only). PTIME INT
EXT External (terminal multiplexers only). (TERM)
LOOP Loop (terminal multiplexers only).
PTIME Primary timing mode EXT External (drop/insert multiplexers only). THRU
(DI-A, DI-B) THRU Through (drop/insert multiplexers only).
E1 line loopback Activate the line loopback of the target CM4 module. LINE-LB ON OFF
OFF Deactivate the line loopback of the target CM4 module.
E1 payload loopback ON Activate the payload loopback of the target CM4 module. PAYLD-LB
CAUTION: To avoid system miso
peration, do not activate
the payload and equipment loopbacks simultaneously.
OFF
Deactivate the payload loopback of the target CM4 module. OFF
EQPT-LB E1 equipment
loopback
ON Activate the equipment loopback of the target CM4 module.
CAUTION: To avoid system miso
peration, do not activate
the payload and equipment loopbacks simultaneously.
OFF
OFF Deactivate the equipment loopback of the target CM4
module.
FAST Fast Reframing ON Activate Fast Reframing OFF
via Time Slot 30 OFF Deactivate Fast Reframing
CSU CSU mode RFL Not CSU mode RFL
ANSI ANSI CSU mode
ATT AT&T CSU mode
MAIN Main module ON Force to report an on-board trouble ON
forced-switch
config. parameters
OFF Do not force to report an on-board trouble
SWITCH Standby module AUTO Allow automatic switch operation AUTO
forced-switch MAIN Activate main module
config. parameters STANDBY Activate standby module
PMRESET Reset CSU ON Reset CSU counters OFF
counters OFF Do not reset CSU counters
PRSQ Pre-squelch timer 0,0.66,1.3,2.0,2.7,
3.3,4.0,4.6,5.3,6.0,
6.6,7.3,8.0,8.6,9.3,
DISA
0ms, 0.66ms, 1.3
ms, 2.0ms, 2.7ms, 3.3ms, 4.0ms, 4.6ms,
5.3ms, 6.0ms, 6.6ms, 7.3ms, 8.0ms, 8.6ms, 9.3ms
DISA = disable squelch function
DISA
POSQ Post-squelch timer 0,0.66,1.3,2.0,2.7, 0ms, 0.66ms, 1.3ms, 2.0ms, 2.7ms, 3.3ms, 4.0ms, 4.6ms,
5.3ms, 6.0ms, 6.6ms, 7.3ms, 8.0ms, 8.6ms, 9.3ms
DISA = disable squelch function
DISA
3.3,4.0,4.6,5.3,6.0,
6.6,7.3,8.0,8.6,9.3,
DISA
SWAP Swap delay in
seconds
0.6, 1.2, 2.4, 4.8,
9.6, 19
0.6s, 1.2s, 2.4s, 4.8s, 9.6s, 19s 0.6s
CRC4 CRC4 error checking ON, OFF Cyclic Redundancy Check ON
FRAMER* Framer Mode T1, E1 T1 = 1.544 mHz, E1 = 2.048 mHz T1
HEAD I/O interface CMI Optical Interface 100
100 (T1 only) 100 Ohm
75 (E1 only) 75 Ohm
120 (E1 only) 120 Ohm
*NOTE: These parameters cannot be set via SCL, but can be set via the front panel switches and can be viewed in a
“CONFIG?” response.
IMUX 2000E1 RFL Electronics Inc.
February 28, 2006 7-25 (973) 334-3100
