3.1.7.3 Switch-control Hierarchy.

FRONT-PANEL MODE SWITCH

STANDBY AUTO

MAIN

Force

Standby

Active

Force

Main

Active

SOFTWARE SWITCH PARAMETER

STANDBY AUTO

MAIN

Force

Standby

Active

Force

Main

Active

MAIN ON/OFF PARAMETER

ON OFF

Force Main

to “fail”.

Switch to

Standby

no onboard

trouble.

Remain in

present state

(Main or

Standby). If

the Main fails,

switch to the

Standby if

there is no

on-board

trouble.

IMUX 2000E1 RFL Electronics Inc.

January 23, 2004 3-12 (973) 334-3100
