Table 7-2. Valid command field entries
Command Description
SET
Used to set a particular parameter on the common module, channel module, ILS, or DACS identified in the
suba
ddress field. Every SET command must include a valid parameter name and value in the parameter
field.
Command example:
1:TERM:SET:CODE=HDB3;
Response:
*OK;
CONFIG?
Lists the configuration settings for the module named in the sub
address field. The parameter field in a
"CONFIG?" command should be left blank.
Command example:
99DI-A:CONFIG?:;
Response:
*OK
FROM NET ADDRESS=99
PTIME=THRU
FTIME=
FRAMING=CCS
CODE=AMI
FAST REFRAME=ON;
STATUS?
When addressed to a Channel Module, lists the state of all "S" (status)
parameters associated with that
module.
Command example:
34:C5:STATUS?:;
Response:
*OK
FROM NET ADDRESS=46
CHANNEL CARD 11,TYPE 79;
When addressed to a CM4 module, lists the E1 interface and timing status information associated with that
m
odul
e.
Command example:
34:TERM:STATUS?:;
Response:
*OK
FROM NET ADDRESS=5;
In all cases, the "STATUS?" command's parameter field should be left blank.
<<Table continues on next page>>
