Table 11-1. Differences between IMUX 2000 Optical Interface Adapters
Model Designation Part
Number
Light Source Wavelength/
Mode
Connector Peak Light
Level*
Average
Light Level*
1300-nm SM LED OIA-R
CM4
107455-201 LED 850 nm Singlemode ST -14dBm -17dBm
1300-nm MM LED OIA-
R CM4
107455-301 LED 1300 nm Multimode ST -10dBm -13dBm
107455-401 LASER 1300 nm Singlemode ST +3dBm 0dBm 1300-nm SM LASER
OIA-R CM4
107455-501 LASER 1550 nm Singlemode ST 0dBm -3dBm1550-nm SM LASER
OIA-R CM4
1550-nm SM 2mW
LASER OIA-R CM4
107455-601 LASER 1550 nm Singlemode ST +3dBm 0dBm
* Light levels are emitter outputs for fiber optic I/O modules, and detector inputs for fiber optic I/O modules.
Table 11-2. Acceptable received fiber optic power levels
Model Designation Part Number Receiver Sensitivity
(Lower Limit)
Receiver Sensitivity
(Lower Limit With
3-dB Margin)
Typical Line Length
1300-nm SM LED OIA-R
CM4
107455-201
-40 dBm -37 dBm 18 mi (29 km)
11 mi (18 km) -40 dBm -37 dBm
107455-301 1300-nm MM LED OIA-R
CM4
-40 dBm -37 dBm 36.5 mi (59 km)
107455-401 1300-nm SM LASER OIA-R
CM4
-40 dBm -37 dBm 56 mi (90 km)
107455-501 1550-nm SM LASER OIA-R
CM4
-40 dBm -37 dBm 70 mi (113 km)
107455-601 1550-nm SM 2mW LASER
OIA-R CM4
