MAIN SHELF
CHANNEL
MODULES
MAIN POWER
REDUNDANT POWER SUPPLY (OPTIONAL)
STANDBY CM4 AND MAIN CM4
(OCCUPY FIRST 2 SLOTS)
PHYSICAL SLOTS 3 - 16 AVAILABLE
FOR CHAN
NEL MODULES
123
16 17 18
CHANNEL
MODULES
1234
16 17 18
CHANNEL
MODULES
1 2 3 4
16 17 18
BUS REPEATER
MODULE
(OCCUPIES 2
CARD SLOTS)
FIRST REPEATER SHELF
SECOND REPEATER SHELF
POWER CABLE
(IF REQUIRED)
POWER CABLE
(IF REQUIRE
D)
SIGNAL
CABLE
SIGN
AL
CABLE
SLOTS FOR OPTIONAL
REPEATER POWER SUPPLIES
16 SLOTS AVAILABLE FOR CHANNEL
16 SLOTS AVAILABLE FOR CHANNEL
Figure 2-7. Front view of multiple repeater shelves
