RFL VF-5C RFL Electronics Inc.
August 13, 2007 6 (973)
334-3100
E&M SIGNALING LEADS CHANNEL# VF IN
R, T
VF OUT
R, T
SG E SB M
1
2
1, 26
5, 30
2, 27
6, 31
3
7
28
32
4
8
29
33
3
4
9, 34
13, 38
10, 35
14, 39
11
15
36
40
12
16
37
41
5
6
17, 42
21, 46
18, 43
22, 47
19
23
44
48
20
24
45
49
MA301
Figure 1. MA-301 Module Adapter
TOP VIEW
RIBBON CABLES
MOTHERBOARD
REAR VIEW
CH5 & CH6
CH3 & CH4
CH1 & CH2
Three VF-5C modules
MA301
MA301
RIBBON CABLES
Figure 2. Connecting up to three RFL VF-5C modules to a single MA-301 Module Adapter.
