IMUX 2000E1 RFL Electronics Inc.
January 1, 2008 4-9 (973) 334-3100
Table 4-2. Current Draw of IMUX Modules Versus Power Supply Capacity For Repeater Shelf
Module +5V
Operating
+15V
Operating
-15V
Operating
Number
Per system
Watts@
+5V
Watts@
+15V
Watts@
-15V
Watts/
card
DS-562I 0.059 0.000 0.000
DS-64NC 0.329 0.000 0.000
DS-961DE 0.107 0.034 0.034
DA-191A 0.067 0.000 0.000
DA-191B 0.067 0.000 0.000
DA-91I 0.080 0.000 0.000
DA-121I 0.080 0.000 0.000
NCM 0.081 0.000 0.000
VF-5AE 0.060 0.030 0.013
VF-5C 0.120 0.070 0.050
VF-6I 0.027 0.016 0.019
VF-8A 0.074 0.031 0.024
VF-15C 0.072 0.049 0.027
VF-16B off hook 0.209 0.094
VF-16B max ring 0.255 0.450
VF-16B ring 0.158 0.110
MTS 0.134 0.000 0.000
MTS I/O 0.080 0.080
Status (no output) 0.140 0.010
Status (8 output) 0.140 0.100
Status (16 output) 0.140 0.200
Telemetry TX 0.060 0.080 0.080
Telemetry RX 0.050 0.100 0.100
Telemetry RX 0.081 0.000 0.000
Bus Repeatewr 0.197 0.000 0.000
SAG Module 0.140 0.000 0.000
MA-271
MA-270R
MA-275R
MA-278
MA-402I 0.044
MA-490 0.140
107455-201
107455-301
107455-401
107455-501
107455-601
Supply +5V +15V -15V watts@volts
Rating (Amps) 4.00 0.75 0.75 amps@volts
1. If total power consumption exceeds 50 watts, additional power supply capacity is required.
