SC6xx: Communication
459
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC672-13 D Controller start up error
The operation panel detects that the controller is down due to other reason shown in
SC672-10, SC672-11, and SC672-12.
• Controller stalled
• Board installed incorrectly
• Controller board defective
• Operation panel connector loose, broken or defective
• Controller late
• Cycle the main power off and on.
• Check the connection of the controller board.
• Replace the controller board.
• Check the control panel harness.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC672-99 D Controller start up error
The operation panel software ended abnormally.
• Controller stalled
• Board installed incorrectly
• Controller board defective
• Operation panel connector loose, broken or defective
• Controller late
• Cycle the main power off and on.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC673-10 D Operation panel Flair communication error (Smart Operation Panel)
This SC is issued only for the machine that has the Smart Operation Panel installed.
• Communication between Smart Operation Panel and main machine (this is called “Flair
communication”) is not sent to Smart Operation Panel.
• SP setting (SP5-748-201) for Smart Operation Panel is not activated.
The CATS module (controller) did not see the response to notification of monitoring service
module (operation panel)
• Cycle the main power off and on.
• Set SP5-748-201 to “1: Connect” if the value is “0: Not connect”
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC681-** D Toner bottle: ID chip communication error
• Corrupted ID data
