Ricoh SP 3710DN Service Manual

Maintenance Mode (for Four-line LCD Models)
SM 5-9 M0C3/M0C4/M0C5/M0C6/M0C7
System
Maintenance
Menu Description
[-0.9 to 0.9 / 0 (Default)/ 0.1 %/step]
Flatbed Main Reg. Adjusts the Flatbed Scan main-scan magnification.
[-0.9 to 0.9 / 0 (Default)/ 0.1 %/step]
Flatbed Sub Reg. Adjusts the Flatbed Scan sub-scan magnification.
[-0.9 to 0.9 / 0 (Default)/ 0.1 %/step]
Factory Default
Menu Description
Factory
Default
Return Does not execute anything. Returns to an upper level.
Execute
Resets all the settings to factory default.
Clears/ resets the contents of the controller memory (all data
programmed by the user, log data application counters) to factory default.
After executing, initial setup menu starts after power-on.
CTL Maintenance
Menu Description
PDL Mode
ON = "PDL Settings" is shown in [Print List/Report] menu (Default)
OFF = "PDL Settings" is hidden
FW Update
Mode
If updating firmware on a machine in which LDAP authentication is set, execute this
mode.
[Execute/ Return]
After pressing “Execute”, the display shows “Please Restart Machine….” Turn the
machine's main power off, and then on. Then the machine activates in a special
boot loader mode. After that, update the firmware via USB cable.
Auto IP
ON = Automatically set an IP address when an IP address cannot be acquired
(Default)
OFF = Continually try to obtain an IP address by DHCP
Disable
USB Port
Sets whether the USB port function is valid or invalid
[Off (Default)/On]
Paas
Validity
Setting
When used to set Paas (Only for CHN)
[Inactive (Default)/ Active]

Ricoh SP 3710DN Specifications

General

Color	No
Duplex printing	-
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printer fonts	PCL, PostScript
Printing colors	Black
Maximum duty cycle	- pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Total input capacity	300 sheets
Total output capacity	125 sheets
Maximum input capacity	550 sheets
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Power consumption (printing)	- W
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR
Sound pressure level (printing)	- dB
Product color	Black, White
Market positioning	Home & office
USB connector	USB Type-B
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
Included cartridge capacity (black)	7000 pages

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
