Exterior Covers (MF Models)
M0C3/M0C4/M0C5/M0C6/M0C7 4-16 SM
4.3.4 RIGHT COVER
1. Remove the front cover (Front Cover).
2. Remove the rear cover (Rear Cover).
3. Remove the three screws of the right cover [A].
4. Pull the rear part of the right cover [A] to release the hook.
The outside of the cover has marks indicating the position of the hooks.
To Next Page
