Product Overview
SM 7-5 M0C3/M0C4/M0C5/M0C6/M0C7
Detailed
Descriptions
7.2.3 DRIVE LAYOUT
No. Item
1. Main motor
2. Duplex motor
3. Registration clutch
4. Relay clutch
5. Paper feed clutch
